7.2kw/9kva prime,8kw/10kva standby,diesel generator powered by Perkins
|
Technical Spec
|
|
Genset
|
Manufacturer
|
New Sunrise
|
|
Model
|
NSP9
|
|
Frequency
|
50hz
|
|
Power
|
Prime Power
|
7.2kw/9kva
|
|
Standby Power
|
8kw/10kva
|
|
Dimension(LxWxH)
|
Open type(mm)
|
1100×500×1000
|
|
Canopy type(mm)
|
2000×950×1050
|
|
Engine
|
Engine Manufacturer
|
Perkins
|
|
Model
|
403D-11G
|
|
Engine type
|
4 stroke, Vertical in-line, 3-cylinder
|
|
Engine speed
|
1500rpm
|
|
Air intake way
|
Naturally Aspirated
|
|
Bore×Stroke (mm×mm)
|
77 x 81
|
|
Displacement(Liter)
|
1.131
|
|
Compression Ratio
|
23:1
|
|
Prime power
|
8.4kW/11.4hp
|
|
Standby Power
|
9.3kW/12.6hp
|
|
Cooling system
|
Water cooled
|
|
Speed Governor
|
Mechanical governor
|
|
Total lubrication system capacity (L)
|
4.9
|
|
Coolant capacity (with radiator) （L）
|
5.2
|
|
Fuel Consumption at 100% Prime power
|
2.9
|
|
Alternator
|
Manufacturer
|
Leroy Somer
|
|
Model
|
LSA40VS1
|
|
Rated voltage
|
400/230V
|
|
AVR model
|
R220
|
|
Excitation
|
Shunt
|
|
Power factor
|
0.8
|
|
Prime Output Power
|
8kw/10kva
|
|
Stamdoby Output Power
|
8.8kw/11kva
|
|
Insulation class
|
H
|
|
Drip proof
|
IP23
|
